Alternators
F032110048 - AlternatorTrade number 110048
Insulated return Yes,Voltage 14,Amp 70,Terminal W,Pulley SP,W plug type 6.30,Pulley Diameter 73.00,Prod. info BN/OE,D+ Position 25,Pulley Distance 72.00,Source Mahle Letrika,Radius 84.50,Belt Adjustment Bracket Hole 1 8.00,Grooves/pulley 1,Regulator type IR,Bracket Hole Size 1 11.00,D+ Size M5,Holder Arm Width 51.00,B+ M6,Fan EF,Radius 2 83.50,Rotation CW,Position 60,B+ Position 40,Belt Adjustment Bracket Hole Position 56,Total Length 180.00
F032110052 - AlternatorTrade number 110052
Terminal W,Insulated return Yes,Voltage 28,Amp 40,Pulley w/o,W plug type 6.30,Bracket Hole Size 1 11.00,Prod. info BN,Bracket Hole Size Rear 14.00,D+ Size M5,D+ Position 5,Holder Arm Width 50.00,B+ M6,Fan EF,Radius 2 82.00,Radius 84.00,Rotation CW,Belt Adjustment Bracket Hole 1 8.20,Regulator type IR,Position 38,B+ Position 50,Belt Adjustment Bracket Hole Position 55,Total Length 177.00
F032110112 - AlternatorTrade number 110112
Terminal W,Voltage 28,Amp 40,Pulley w/o,W plug type M5,Bracket Hole Size 1 11.50,Prod. info BN,D+ Size M4,D+ Position 55,Holder Arm Width 51.00,Servicing Volvo,B+ M6,Fan EF,Radius 2 90.00,Radius 90.00,Belt Adjustment Bracket Hole 1 8.20,Regulator type IR,Position 25,B+ Position 10,Belt Adjustment Bracket Hole Position 57,Total Length 175.50
F032110127 - AlternatorTrade number 110127
Insulated return Yes,Voltage 14,Amp 70,Terminal W,Pulley P,W plug type 6.30,Pulley Diameter 64.00,Prod. info BN,D+ Position 50,Pulley Distance 79.00,Servicing Volvo Penta,Radius 85.00,Belt Adjustment Bracket Hole 1 8.00,Grooves/pulley 1,Regulator type IR,Bracket Hole Size 1 11.00,D+ Size M5,Holder Arm Width 51.00,B+ M6,Fan EF,Radius 2 86.50,Rotation CW,Position 14,B+ Position 58,Belt Adjustment Bracket Hole Position 57,Total Length 179.00
F032110173 - AlternatorTrade number 110173
Voltage 28,Amp 75,Pulley w/o,Bracket Hole Size 1 12.50,Prod. info BN,Bracket Hole Size Rear 12.50,D+ Size M6,D+ Position 45,Holder Arm Width 14.50,Servicing DAF, Clark,B+ M8,Radius 2 107.00,Info NOTE! NOT with insulated return,Mounting Bracket Distance 101.50,Radius 105.00,Rotation CW,Belt Adjustment Bracket Hole 1 1/2" UNC,Regulator type IR,Position 60,B+ Position 15,Belt Adjustment Bracket Hole Position 60,Total Length 246.00
F032110175 - AlternatorTrade number 110175
Insulated return Yes,Voltage 28,Amp 100,Pulley w/o,Radius 4 107.50,Prod. info BN,Bracket Hole Size Rear 13.00,D+ Position 5,Servicing Volvo,Radius 3 106.50,Belt Adjustment Bracket Hole 3 1/2" UNC,Mounting Bracket Distance 103.00,Radius 108.00,Belt Adjustment Bracket Hole 1 1/2" UNC,Regulator type IR,Bracket Hole Size 1 13.00,Belt Adjustment Bracket Hole 2 1/2" UNC,D+ Size M5,Holder Arm Width 14.70,B+ M8,Fan EF,Radius 2 107.00,Rotation CW,Position 60,B+ Position 30,Belt Adjustment Bracket Hole Position 56;60;4,Total Length 249.00,Remarks Fan: HC-CARGO 134317. Pulley: HC-CARGO 131176.
F032110176 - AlternatorTrade number 110176
Insulated return Yes,Voltage 28,Amp 175,Terminal W,Pulley w/o,W plug type M5,Radius 4 104.00,Prod. info BN,Bracket Hole Size Rear 13.00,D+ Position 15,Servicing Volvo Penta,Radius 3 100.00,Belt Adjustment Bracket Hole 3 1/2" UNC,Mounting Bracket Distance 101.50,Radius 108.00,Belt Adjustment Bracket Hole 1 1/2" UNC,Regulator type IR,Bracket Hole Size 1 13.00,Belt Adjustment Bracket Hole 2 1/2" UNC,D+ Size 10-24 UNC,Holder Arm Width 14.70,B+ 5/16" UNC,Fan EF,Radius 2 107.00,Rotation CW,Position 60,B+ Position 30,Belt Adjustment Bracket Hole Position 55;60;5,Total Length 278.00
F032110540 - AlternatorTrade number 110540
Terminal W,Voltage 14,Amp 55,Pulley P,W plug type Plug,Bracket Hole Size 1 10.00,Pulley Diameter 73.50,Prod. info BN,D+ Size Plug,Holder Arm Width 50.50,Pulley Distance 75.00,Servicing Bobcat, OMC,B+ 1/4" UNC,Radius 2 82.00,Radius 81.50,Rotation CW,Belt Adjustment Bracket Hole 1 5/16" UNC,Grooves/pulley 1,Regulator type IR,Position 30,B+ Position 10,Belt Adjustment Bracket Hole Position 60,Total Length 170.00
F032110577 - AlternatorTrade number 110577
Voltage 28,Amp 55,Terminal W,Pulley DP,W plug type 6.30,Radius 4 84.50,Pulley Diameter 74.00,Prod. info BN,D+ Position 30,Pulley Distance 115.00,Radius 3 85.00,Belt Adjustment Bracket Hole 3 10.30,Radius 84.00,Belt Adjustment Bracket Hole 1 10.30,Grooves/pulley 2,Regulator type IR,Bracket Hole Size 1 10.20,Belt Adjustment Bracket Hole 2 10.30,D+ Size Plug,Holder Arm Width 80.00,B+ M6,Radius 2 84.50,Plug no. 1 PL22,Rotation CW,B+ Position 20,Belt Adjustment Bracket Hole Position 50;60;10,Total Length 183.00,Remarks w/ mounting bearing bracket for left and right engine side.
F032110641 - AlternatorTrade number 110641
Voltage 14,Amp 33,Terminal W,Pulley P,W plug type M5,Pulley Diameter 76.00,Prod. info BN,D+ Position 55,Pulley Distance 76.50,Servicing Deutz, Fendt, Case, Claas, Goldoni,Radius 86.00,Belt Adjustment Bracket Hole 1 8.00,Grooves/pulley 1,Regulator type IR,Bracket Hole Size 1 8.00,D+ Size M5,Holder Arm Width 56.00,B+ M6,Radius 2 79.00,Rotation CW,Position 30,B+ Position 5,Belt Adjustment Bracket Hole Position 50,Total Length 162.00
