F032234160 - Solenoid Switch
Trade number 234160
Replacing and BOMs
OEM number
31210P2C004HONDA
31210P2A004HONDA
Competitor References
71135ACCURATE
SS9013AUTOSTARTER POLAND
F042S10381BOSCH
F042010381BOSCH
234160HC-CARGO
234160MITSUBA ELECTRIC
SS1693NEW-ERA
SNLS6033UNIPOINT
668504WAI
F032234160 - Solenoid Switch
Details & description
Voltage 12, No./mount. holes 3, No./terminals 3, Terminal 50/mm 6.30, Coil Bolt Length 8.00, Plunger Outer Diameter 22.00, B+ M8, Terminal 50 Spade, B+ Height 11.50, Coil Bolt Diameter M8, Outer Diameter 51.70, Amount of Mounting Holes 3, Total Length 86.00
Product information
Voltage:12
No./mount. holes:3
No./terminals:3
Terminal 50/mm:6.30
Coil Bolt Length:8.00
Plunger Outer Diameter:22.00
B+:M8
Terminal 50:Spade
B+ Height:11.50
Coil Bolt Diameter:M8
Outer Diameter:51.70
Amount of Mounting Holes:3
Total Length:86.00
