F032133857 - Solenoid Switch
Trade number 133857
Replacing and BOMs
OEM number
8915857MERCURY MARINE
8968258MERCURY MARINE
89638258MERCURY MARINE
8976454MERCURY MARINE
8761053MERCURY MARINE
182869OMC
Competitor References
F042S10126BOSCH
F042010126BOSCH
133857HC-CARGO
15487PRESTOLITE ELECTRIC
SAZ4201AHYPRESTOLITE ELECTRIC
SAZ4201APPRESTOLITE ELECTRIC
SAZ4201BCPRESTOLITE ELECTRIC
SAZ4201EYPRESTOLITE ELECTRIC
SAZ4201UPRESTOLITE ELECTRIC
15275PRESTOLITE ELECTRIC
15351PRESTOLITE ELECTRIC
15368PRESTOLITE ELECTRIC
15400PRESTOLITE ELECTRIC
SNLS165MUNIPOINT
67710WAI
F032133857 - Solenoid Switch
Details & description
Intermittent load 800 Amp, Voltage 12, Amp 100, No./mount. holes 2, No./terminals 4, Outer Diameter 48.20, Amount of Mounting Holes 2, Remarks 3.95-4.15 coil resistance. N.O. Terminals: 5/16" UNC. Coil Terminals: 10-32 UNF., Total Length 55.50
Product information
Intermittent load:800 Amp
Voltage:12
Amp:100
No./mount. holes:2
No./terminals:4
Outer Diameter:48.20
Amount of Mounting Holes:2
Remarks:3.95-4.15 coil resistance. N.O. Terminals: 5/16" UNC. Coil Terminals: 10-32 UNF.
Total Length:55.50
Replacing and BOMs
OEM number
8915857MERCURY MARINE
8968258MERCURY MARINE
89638258MERCURY MARINE
8976454MERCURY MARINE
8761053MERCURY MARINE
182869OMC
Competitor References
F042S10126BOSCH
F042010126BOSCH
133857HC-CARGO
15487PRESTOLITE ELECTRIC
SAZ4201AHYPRESTOLITE ELECTRIC
SAZ4201APPRESTOLITE ELECTRIC
SAZ4201BCPRESTOLITE ELECTRIC
SAZ4201EYPRESTOLITE ELECTRIC
SAZ4201UPRESTOLITE ELECTRIC
15275PRESTOLITE ELECTRIC
15351PRESTOLITE ELECTRIC
15368PRESTOLITE ELECTRIC
15400PRESTOLITE ELECTRIC
SNLS165MUNIPOINT
67710WAI
