Details & description

kW 0.9/1.0/1.2, Voltage 12, Commutator Diameter 30.20, Commutator Distance 8.90, OD/spline/teeth 14.20, No./bars 21, Commutator Height 31.70, Bar length 4.40, Commutator Inner Diameter 11.80, Bar Distance 1.80, No./teeth 9, Core Diameter 47.00, Shaft length 135.00, Bar Cross Distance 31.20, Commutator End Shaft Diameter 8.00, Bar Lane Height 21.30, Spline Teeth Length 24.00, Commutator Outer Diameter 40.20, Drive End Inside Shaft Diameter 15.00, Rotation CW
