Details & description

Voltage 14, Amp 120, Communication LIN, Pulley SP/FW, Pulley Diameter 51.70, Bracket Hole Size Rear 12.50, Pulley Distance 11.50, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 51.00, Radius 84.50, Belt Adjustment Bracket Hole 1 10.50, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 12.50, Terminal type COM, Holder Arm Width 71.50, B+ M8, Radius 2 87.00, Plug no. 1 PL174, Rotation CW, B+ Position 16, Belt Adjustment Bracket Hole Position 4, Total Length 186.50
