Voltage 14, Amp 180, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Grooves/pulley 7, Regulator type IR, Belt Adjustment Bracket Hole 1 9.30, Mounting Bracket Distance 40.80, Radius 87.00, Pulley Diameter 49.00, Bracket Hole Size Rear 10.60, Communication BSS, Pulley SP/FW, Pulley Distance 31.00, Plug no. 1 PL86, Radius 2 87.00, B+ M8, Rotation CW, Bracket Hole Size 1 9.30, Terminal type COM, Holder Arm Width 62.70, Total Length 179.00, B+ Position 10
