Voltage 14, Amp 105, Grooves/pulley 6, Regulator type IR, Belt Adjustment Bracket Hole 1 M8, Mounting Bracket Distance 81.80, Radius 78.00, Pulley Diameter 55.70, Prod. info BN, Bracket Hole Size Rear 10.20, Pulley SP, Pulley Distance 33.00, Servicing Dodge, Eagle, D+ Position 15, Plug no. 1 PL24, Radius 2 78.00, B+ M6, Rotation CW, Bracket Hole Size 1 10.20, Holder Arm Width 13.00, D+ Size Plug, Belt Adjustment Bracket Hole Position 60, Total Length 172.00, Position 25, B+ Position 35, Remarks Replacing: CS130.
